Watts LFF115 300 8 - Part of the LFF115 Series

This 8 inch, globe, Class 300 Flanged ACV is armed with ArmorTek^®, a patented 3-part advanced epoxy coating system designed to limit both microbial induced (MIC) and exposed metal substrate corrosion. This pressure reducing control valve is designed to automatically reduce a fluctuating higher inlet pressure to a constant lower downstream pressure regardless of varying flow rates. The quick closing action of the valve limits possible damaging high inlet pressure from passing through the valve to downstream piping.

Features

• Body construction with patented 3-part ArmorTek epoxy coating for advanced corrosion resistance
• Globe body pattern with Class 300 flanged end connections
• Range 20-175 psi (standard)
• Inlet/outlet gauge ports, gauge not included

Specifications
Adjustable Reduced Pressure Range	20 - 175 PSI
Adjustable Reduced Pressure Range-BAR	1.4 - 12.1 BAR
ArmorTek Technology	No
Body Material	Ductile Iron
Brand	Watts
Coating	Bonded Epoxy
EAN	098268616088
Inlet Connection Size	8 IN
Inlet Connection Type	Flanged Joint
Lead Free	YES
Maximum Operating Temperature-Fahrenheit	160
Maximum Working Pressure-PSI	400
Outlet Connection Size	8 IN
Outlet Connection Type	Flanged Joint
Part Number	2GE00017
Series	LFF115
Valve Style	Classic
Warranty Name	Standard Watts Warranty

• Schematic - Automatic Control Valve LFF115
• Schematic - Automatic Control Valve LFF115 (Spanish)

UPC - 098268616088
