Watts LF530-C 3/4 - Part of the LF530C Series

This 3/4 inch lead free calibrated pressure relief valve is designed for use only as protection from the build up of excessive pressure in systems containing water, oil or air. It features a lead free brass body with 3/4 inch NPT male inlet and 1/2 inch NPT female (drain) outlet, stainless steel spring, lead free brass bonnet and a Buna-N disc and O-ring. The pressure relief spring adjustable range is 100 to 300 psi (6.9 to 20.7 bar).

Features

• Lead free brass body construction
• All stainless steel adjustable spring
• Adjustable range 100 to 300 psi
• Buna-N disc on machined body seat

Specifications
Body Material	Lead Free Brass
Brand	Watts
Buy American Act Compliant	YES
EAN	098268435207
Inlet Connection Size	3/4 IN
Inlet Connection Type	Male Threaded
Inlet Thread Type	NPT
Lead Free	YES
Maximum Working Pressure-PSI	300
Outlet Connection Size	1/2 IN
Outlet Connection Type	Female Threaded
Outlet Thread Type	NPT
Part Number	0556036
Pressure Range	50 to 175 PSI
Pressure Relief Setting-PSI	150
Series	LF530C

• Specification Sheet - LF53, LF530C

UPC - 098268435207
