Watts - FD-530 - Large Capacity Bottom Outlet Offset Parking Area Drain

The Watts FD-460-F is an epoxy-coated cast-iron area drain engineered for heavy commercial traffic applications. It features an anchor flange for secure mounting, twin weepholes to manage perimeter seepage, a fixed 12¾″ × 12¾″ square top with a heel-proof ductile-iron grate, and a standard no-hub outlet connection.

Key Features

• Fixed 12¾″ × 12¾″ square top with heel-proof ductile-iron grate suited for high-traffic zones

• Epoxy-coated cast-iron body with anchor flange and dual weepholes for enhanced drainage integrity

• No-hub outlet connection as standard, with multiple outlet size options available

• Rated for extra-heavy-duty (XHD) traffic conditions, supporting up to 7,500–10,000 lbs live load

• Compatible with optional accessories including sediment buckets, trap primer tapping, and alternative finishes

Downloads:

• Specification Sheet
