Watts BF-04-111-15-M2 12 - Part of the BF-04 Series

Product image 1

Watts BF-04-111-15-M2 12 - Part of the BF-04 Series

This 12 inch wafer style butterfly valve, model BF-04-111-15-M2, is used in HVAC, irrigation, OEM, commercial, and institutional applications and wherever positive shutoff is required to control the flow of liquids, gases, and slurries. It features cast iron body construction, ductile iron disc, EPDM seat, stainless steel shaft, mounting pad for 10 position lever.

Features
  • Cast iron body
  • Ductile iron disc
  • EPDM seat
  • Lever handle
Specifications
Body Material Ductile Iron
Brand Watts
Class Rating 125 or 150
Control Type Lever Handle
CV Rating 8250 GPM
Disc Material Ductile Iron
EAN 098268607383
Inlet Connection Size 12 IN
Inlet Connection Type Wafer
Lead Free YES
Maximum Operating Temperature-Fahrenheit 248
Maximum Working Pressure-PSI 200
Minimum Temperature-Fahrenheit 33
Operating Torque-Dry 7071 in-lbs
Operating Torque-Wet 3300 in-lbs
Outlet Connection Size 12 IN
Outlet Connection Type Wafer
Part Number 0525915
Seat Material EPDM
Series BF-04
Silicone Free Yes
Stem Shaft Material 416 Stainless Steel
Valve Style Wafer
  • Specification Sheet - BF-03-M2, BF-04-M2
UPC - 098268607383
$814.38

Original: $2,326.80

-65%
Watts BF-04-111-15-M2 12 - Part of the BF-04 Series—

$2,326.80

$814.38
